# Fibonacci with linear algebra

## Fibonacci sequence

The Fibonacci sequence is one of the few sequences in mathematics that are widely known among people outside of this field. Let’s remind how it works: You start with 0 and 1, then add the two previous terms to generate the next one.

$$0 \hspace{1em} 1 \hspace{1em} 1 \hspace{1em} 2 \hspace{1em} 3 \hspace{1em} 5 \hspace{1em} 8 \hspace{1em} 13 \hspace{1em} 21 \hspace{1em} 34\dots$$

If we define $$f_n$$ as the $$n$$-th element in this sequence, the following holds:

\begin{cases} \begin{align*} f_0 &= 0 \\ f_1 &= 1 \\ f_{n} &= f_{n-1} + f_{n-2}, \hspace{1em} \text{for all } n \ge 2 \end{align*} \end{cases}

We can use this definition to compute any Fibonacci number, but it would take $$\mathcal{O}(n)$$ additions. What if we want the $$10^{16}$$-th Fibonacci number? (of course, it’s too large, but maybe we want to compute some of the last digits, or use some extended but finite precision float numbers for the computation). I don’t think we want to wait some months until the computation is done. Let’s try to find a different approach.

Linear recurrences are related to linear algebra, as usually happens with linear things. Let’s use a linear algebra approach.

## Matrix form

Since every new term requires the last two terms, let’s define the $$n$$-th Fibonacci vector as:

$F_n = \begin{pmatrix} f_{n} \\\ f_{n-1} \end{pmatrix}$

In the regular sequence form, we were using $$(f_{n-1}, f_{n-2})$$ to get $$f_{n}.$$ It’s reasonable to think that now we can get $$F_n$$ from $$F_{n-1} \sim (f_{n-1}, f_{n-2}).$$ Let’s try to find a linear application $$M$$ such that $$F_n = M F_{n-1}.$$

$F_n = M F_{n-1} \iff \begin{pmatrix}f_{n} \\\ f_{n-1}\end{pmatrix} = \begin{pmatrix}a & b \\\ c & d\end{pmatrix} \begin{pmatrix}f_{n-1} \\\ f_{n-2}\end{pmatrix} = \begin{pmatrix}a f_{n-1} + b f_{n-2} \\\ c f_{n-1} + d f_{n-2}\end{pmatrix}$

Let’s find the constants $$a,b,c,d$$ that satisfy the equation above. Starting with the bottom row, it’s pretty clear that $$d = 0$$ and $$c = 1.$$ Then looking at the top row, we use the definition of $$f_n$$ and get $$a = b = 1.$$ There are no other possible constants that satisfy that equation, so we found the unique linear application that gives us the next Fibonacci vector.

$\begin{pmatrix}f_{n} \\\ f_{n-1}\end{pmatrix} = \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \begin{pmatrix}f_{n-1} \\\ f_{n-2}\end{pmatrix}$

Moreover, we can repeat substitution with this equation to get an interesting result:

\begin{align*} \begin{pmatrix}f_{n} \\\ f_{n-1}\end{pmatrix} &= \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \begin{pmatrix}f_{n-1} \\\ f_{n-2}\end{pmatrix} = \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \left[ \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \begin{pmatrix}f_{n-2} \\\ f_{n-3}\end{pmatrix} \right] \\ &= \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \left[ \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \left\{ \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix} \begin{pmatrix}f_{n-3} \\\ f_{n-4}\end{pmatrix} \right\} \right] = \\ &= \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix}^3\begin{pmatrix}f_{n-3} \\\ f_{n-4}\end{pmatrix} = \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix}^4\begin{pmatrix}f_{n-4} \\\ f_{n-5}\end{pmatrix} = \dots\\ \dots &= \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix}^{n-1}\begin{pmatrix}f_{1} \\\ f_{0}\end{pmatrix} = \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix}^{n-1}\begin{pmatrix}1 \\\ 0\end{pmatrix} \end{align*}

This is a matrix closed form for the $$n$$-th Fibonacci number, which may be written in the following nicer form:

## The matricial expression

$\begin{pmatrix}f_{n+1} \\\ f_{n}\end{pmatrix} = \begin{pmatrix}1 & 1 \\\ 1 & 0\end{pmatrix}^{n}\begin{pmatrix}1 \\\ 0\end{pmatrix}$

Is this a real improvement somehow? If the exponent is computed in a naive way, it will cost $$\mathcal{O}(n)$$ additions and multiplications, but we can use fast exponentiation, which is simple and computes the result in $$\mathcal{O}(\log n).$$ What an improvement! Thank the linear algebra.

But linear algebra can do more for us! Now we can also find a closed-form expression for $$f_n.$$ We will use the power of the Jordan form! The idea is that we decompose $$M$$ in a base that makes $$M$$ as diagonal as possible. Since $$M$$ is a real symmetric matrix, the Spectral Theorem ensures we can diagonalize it! And the Jordan form will do the job.

We’ll find matrices $$J, P$$ such that $$J$$ is diagonal and $$M = PJP^{-1}.$$ Note that now exponentiation is pretty easy since $$M^n = P J^n P^{-1},$$ and $$J^n$$ can be computed by simply exponentiating the diagonal elements to the $$n$$-th power.

## Jordan form using SymPy

Since I am lazy, I will use SymPy, a Python symbolic algebra library. I run it on a Jupyter notebook:

$\left[\begin{matrix}1 & 1\\1 & 0\end{matrix}\right]$
$\left[\begin{matrix}\frac{1}{2} - \frac{\sqrt{5}}{2} & 0\\0 & \frac{1}{2} + \frac{\sqrt{5}}{2}\end{matrix}\right]$

$$J$$ it’s the diagonal matrix of the eigenvalues of $$M,$$ which are the roots of the characteristic polynomial of $$M$$:

$0 = \det(M-\lambda I) = \begin{vmatrix}1-\lambda & 1 \\\ 1 & -\lambda\end{vmatrix} = (1-\lambda)(-\lambda) - 1 = \lambda^2 - \lambda - 1$

The solutions are:

$\lambda_{-} = \frac{1-\sqrt{5}}{2}, \hspace{1em} \lambda_{+} = \frac{1+\sqrt{5}}{2}$
$\left[\begin{matrix}\frac{1}{2} - \frac{\sqrt{5}}{2} & \frac{1}{2} + \frac{\sqrt{5}}{2}\\1 & 1\end{matrix}\right]$
$\left[\begin{matrix}- \frac{\sqrt{5}}{5} & \frac{\sqrt{5}}{10} + \frac{1}{2}\\\frac{\sqrt{5}}{5} & \frac{1}{2} - \frac{\sqrt{5}}{10}\end{matrix}\right]$
$\left[\begin{matrix}\frac{2^{- n} \sqrt{5} \left(- \left(1 - \sqrt{5}\right)^{n} + \left(1 + \sqrt{5}\right)^{n}\right)}{5}\\\frac{2^{1 - n} \sqrt{5} \left(- \left(1 - \sqrt{5}\right)^{n - 1} + \left(1 + \sqrt{5}\right)^{n - 1}\right)}{5}\end{matrix}\right]$

And that’s it! All computations are doable by hand, but using SymPy we get in a few lines of code our desired result:

$F_n = \begin{pmatrix}f_{n} \\\ f_{n-1}\end{pmatrix} = \left(\begin{matrix}\frac{2^{- n} \sqrt{5} \left(- \left(1 - \sqrt{5}\right)^{n} + \left(1 + \sqrt{5}\right)^{n}\right)}{5}\\\frac{2^{1 - n} \sqrt{5} \left(- \left(1 - \sqrt{5}\right)^{n - 1} + \left(1 + \sqrt{5}\right)^{n - 1}\right)}{5}\end{matrix}\right)$

## The closed-form expression

Comparing the first entries of the previous vectors we have:

\begin{align*} f_{n} &= \frac{2^{- n} \sqrt{5} \left[- \left(1 - \sqrt{5}\right)^{n} + \left(1 + \sqrt{5}\right)^{n}\right]}{5} \\ &= \frac{2^{-n}}{\sqrt{5}} \left[ \left(1 + \sqrt{5}\right)^{n} - \left(1 - \sqrt{5}\right)^{n} \right] \\ &= \frac{1}{\sqrt{5}} \left[ {\left( \frac{1+\sqrt{5}}{2} \right)}^n - {\left( \frac{1-\sqrt{5}}{2} \right)}^n \right] \end{align*}

Linear algebra did an amazing job here, allowing us to find both an efficient computation method and a closed-form formula by (almost) the same price :)

## The Golden ratio

The Golden ratio is the proportion $$\varphi$$ of any two lengths $$a, b \in \mathbb{R}^{+}$$ satisfying:

$\varphi := \frac{a}{b} = \frac{a+b}{a}$

Notice that $$\varphi$$ is uniquely defined since $$\varphi \in \mathbb{R}^{+}$$:

$\frac{a}{b} = \frac{a+b}{a} \iff \frac{a}{b} = 1 + \frac{b}{a} \iff \varphi = 1 + \frac{1}{\varphi} \iff \varphi^2 = \varphi + 1$

This quadratic equation has only one positive solution:

$\varphi = \frac{1+\sqrt{5}}{2}$

Notice that the Golden ratio is defined as the positive solution to $$\varphi^2 = \varphi + 1 \iff \varphi^2 - \varphi - 1 = 0.$$
Sounds familiar? The characteristic polynomial of $$M$$ is $$\lambda^2 - \lambda - 1$$, which is the same expression as the Golden ratio. This is why the Golden ratio appears in the closed-form expression if we substitute $$\varphi$$:

$f_n = \frac{\varphi^n - (1-\varphi)^n}{\sqrt{5}}$

Now that we have shown the relation between Fibonacci and the Golden ratio, we can make an interesting observation:

Notice that $$\varphi \approx 1.618,$$ and $$(1-\varphi) \approx -0.618.$$ In the previous expression, the dominating term is $$\varphi^n,$$ and $$(1-\varphi)^n$$ will become closer to $$0$$ as $$n$$ increases. This means that for big enough $$n$$, $$\ f_n \approx \varphi^n / \sqrt{5}$$.

## The ratio of consecutive Fibonacci numbers is the Golden ratio!

We have seen that $$\ f_n \approx \varphi^n / \sqrt{5}.$$ Intuitively, this implies that the ratio $$f_{n+1}/f_n \to \varphi$$ as $$n$$ increases. Let’s prove it by computing $$\lim_{n \to \infty} f_{n+1}/f_n$$

\begin{align*} \lim_{n \to \infty} \frac{f_{n+1}}{f_n} &= \lim_{n \to \infty} \frac{\varphi^{n+1} - (1-\varphi)^{n+1}}{\sqrt{5}} \bigg/ \frac{\varphi^n - (1-\varphi)^n}{\sqrt{5}} = \lim_{n \to \infty} \frac{\varphi^{n+1} - (1-\varphi)^{n+1}}{\varphi^{n} - (1-\varphi)^{n}} = \\ &= \lim_{n \to \infty} \frac{\varphi^n \left[\varphi - \frac{(1-\varphi)^{n+1}}{\varphi^n}\right]}{\varphi^n \left[ 1 - \frac{(1-\varphi)^{n}}{\varphi^n}\right] } = \lim_{n \to \infty} \frac{\varphi - \frac{(1-\varphi)^{n+1}}{\varphi^n}}{1 - \frac{(1-\varphi)^{n}}{\varphi^n}} = \frac{\lim_{n \to \infty} \varphi - \frac{(1-\varphi)^{n+1}}{\varphi^n}}{\lim_{n \to \infty} 1 - \frac{(1-\varphi)^{n}}{\varphi^n}} \end{align*}

But $$\|1-\varphi\| < 1 \implies (1-\varphi)^n \to 0,$$ and $$\varphi^n \to \infty,$$ so we have $$\lim_{n \to \infty} (1-\varphi)^n/\varphi^n = 0$$. Finally, our desired result:

$\lim_{n \to \infty} \frac{f_{n+1}}{f_n} = \varphi$
